Central vacuum cleaner
Halton’s unique module design of central vacuum cleaning, developed together with the Technical University of Tampere, Finland offers several benefits.
Halton delivers central vacuum cleaning system ideally for hotel, restaurant, industry, oil rig, vessel and offshore…
The module design minimizes investment and maintenance. The system has a long life cycle, low life cycle costs including low maintenance needs.
A module contains a central unit (a complete unit with cyclone and cartridge filter, dust container/dust pack, electric and logic control cabin, compressor), pipes, cable to inlet valves, inlet valves, cleaning valves and pneumatic pipes and cleaning tools. When a cleaning hose is plugged in an inlet valve, it starts a central unit. Sensors optimize vacuum cleaning power and minimize electric consumption continuously. When unplugged, the system is idle. One module serves 1-6 simultaneous users.
Principle
Halton ProClean vacuum cleaning system is user-friendly for its automatic control of vacuum level, filter and pipe cleaning. The system can be operated by plugging in the dust collector hose or by a timing device. The capacity level is adjusted to maintain continuous suction pressure, regardless of the number of users.
Minimal maintenance, thanks to automatic functions and robust components. 80-liter dust container, with monthly replaceable plastic bag. Cyclone pre-filter box with high durability and automatic filter cleaning. Turbine channels and components are of industrial quality that require zero annual maintenance.
The system can be monitored and controlled automatically. Bulkhead and other through-pipes are implemented similarly to drainage system.
Characteristics
- Ecological: The system is designed for long-term durability. Besides, the Proclean has been proven to be 55% faster than traditional system.
- Healthy: Using Halton ProClean helps provide better environment due to its ability to eliminate harmful partical matter without creating swirling dust currents in the air.
- Image – Green value: The device represents sustainable development and a commitment to protect environment.
- Low noise: Proclean operates smoothly and odorless. No need for maintenance clearance.
- Effective: fast, light and easy to use, saving work effort.
- Safer: No tangled power cords like conventional vacuum cleaners with short cords, avoiding electrical risk.
- Space saving: Optimize space for public areas.
- Low-maintenance: low technical requirements, cost saving
- A/C energy saving: keep air cleaners, thus reducing need for cleaning and replacing air filter.
Material
Item | Material | Finishing |
Frame | Carbon steel | Electrostatic coating |
Optional piping | Stainless steel EN 1.4301 (AISI304), EN 1.4404 (AISI316L), PVC-U | – |
Outlet valve | Steel | Galvanised |
Inlet valve | Stainless steel EN 1.4301 (AISI304) | – |
